The Vulkan Small Scissor Lift VL-616P combines a movable low-profile layout with imported hydraulic seals, Q345 solid-steel scissor arms, and an extendable platform. Its 24 V control and foot-protection design support the tyre-service, repair, replacement, and oil-change uses identified in the manual. The product family includes 3.0- and 3.2-tonne variants with published lifting-height, platform, pressure, motor, voltage, and net-weight specifications.
KEY FEATURES
- Movable low-profile scissor-lift design
- 105 mm minimum height for on-ground installation
- 1,420 mm main platform length
- Platform extension to 2,000 mm
- Imported hydraulic seals
- Q345 solid-steel scissor arms
- Maximum lifting height of 1,000 mm
- Optional height adapters
- Foot-protection design
- 24 V control system
- Suitable for tyre service and vehicle repair
- Suitable for tyre replacement and oil changes
- Manual-listed 3.0- and 3.2-tonne capacities
- 25 MPa system pressure
- 2.2 kW motor with 380 V supply
- Official net-weight options of 700 and 720 kg
- Lifting Capacity Options: 3.0 and 3.2 tonnes
- Lifting Height: 1,000 mm
- System Pressure: 25 MPa
- Motor Power: 2.2 kW
- Voltage: 380 V
- Minimum Height: 105 mm
- Platform Length Range: 1,420-2,000 mm
- Official Net Weight Options: 700 and 720 kg
